Home>Products>Ball Bearings>TIMKEN 3MM9108WI TUH image

TIMKEN 3MM9108WI TUH image

Back to product page

TIMKEN 3MM9108WI TUH Characteristics

C:17 mm
r min.:1,1 mm
da min.:23,5 mm
Da max.:55,5 mm
ra max.:1 mm
Weight:0,27 Kg
Basic dynamic load rating (C):22,7 kN
Basic static load rating (C0):10,8 kN
(Grease) Lubrication Speed:14 000 r/min
(Oil) Lubrication Speed:16 000 r/min
rs min:1.1 mm
Radial clearance class:CN
Mass:0.27 kg
Dynamic load, C:22.7 kN
Static load, C0:10.8 kN
Fatigue limit load, Cu:0.49 kN
f0:11.1
Nlim (oil):16,000 rpm
Nlim (grease):14,000 rpm
Min operating temperature, Tmin:-20 °C
Max operating temperature, Tmax:120 °C
Characteristic cage frequency, FTF:0.34 Hz
Characteristic rolling element frequency, BSF:2.79 Hz
Characteristic outer ring frequency, BPF0:2.04 Hz
Characteristic inner ring frequency, BPFI:3.96 Hz
da min:23.5 mm
Da max:55.5 mm
ra max:1 mm
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:0.27
Product Group:B00308
Enclosure:Open
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:17MM Bore; 62MM Outside Diameter; 17MM Outer Race Diameter; Open; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6403
Weight / LBS:0.595
Outer Race Width:0.669 Inch | 17 Millimeter
Bore:0.669 Inch | 17 Millimeter
Outside Diameter:2.441 Inch | 62 Millimeter
bore diameter::17 mm
finish/coating::Uncoated
outside diameter::62 mm
bearing material::High Carbon Chrome Steel
overall width::17 mm
cage material::Steel
bore type::Round
inner ring width::17 mm
closure type::Open
outer ring width::17 mm
row type & fill slot::Single Row Non-Fill Slot
maximum rpm (grease)::14000 rpm
snap ring included::Without Snap Ring
maximum rpm (oil)::16000 rpm
internal clearance::CN
fillet radius::1.1 mm
operating temperature range::-40 to 120 ºC
maximum rpm::16000 RPM
dynamic load capacity::22700 N
series::64
static load capacity::10800 N
manufacturer product page::Click here
precision rating::Class 0
