NTN ML71915HVDUJ74S - Leader Industrial Manufacture

✖

Home>Products>Ball Bearings>NTN ML71915HVDUJ74S image

NTN ML71915HVDUJ74S image

NTN ML71915HVDUJ74S Characteristics

Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Contact Seal
Internal Clearance:C3-Loose
Inch - Metric:Metric
Long Description:45MM Bore; 85MM Outside Diameter; 19MM Outer Race Diameter; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6209DDUC3
Weight / LBS:0.405
d:1.772 Inch | 45 Millimeter
D:3.346 Inch | 85 Millimeter
Outer Race Width:0.748 Inch | 19 Millimeter
bore diameter::45 mm
static load capacity::20400 N
outside diameter::85 mm
precision rating::ABEC 1 (ISO Class Normal)
overall width::19 mm
finish/coating::Uncoated
bore type::Round
cage material::Steel
closure type::Double Sealed
outer ring width::19 mm
row type & fill slot::Single Row Non-Fill Slot
fillet radius::1.1 mm
internal clearance::C3
maximum rpm::5300 RPM
operating temperature range::-10 to +100 °C
series::62
dynamic load capacity::31500 N
