TIMKEN 3MMV9113HXVVSULFS637 Characteristics

UPC Code:0883450509053
Type E Open Cover Number:EUDR-3 3/16
Dimension B:5 in
Dimension L:14 in
Dimension A:3-1/2 in
Dimension J Min.:10-13/16 in
Dimension J Max.:11-3/16 in
Bolt Diameter:7/8 in
Dimension N:1 in
Dimension N1:1-3/16 in
Dimension H1:2-1/4 in
Dimension H2:7-1/2 in
Dimension d1:5-17/32 in
Dimension H:3-3/4 in
Dimension Ac:6.1 in
Dimension d2:6.7 in
e:0.50
X (if Fa/Fr ≤ e):0.87
Y (if Fa/Fr ≤ e):1.71
X (if Fa/Fr > e):0.7
Y (if Fa/Fr > e):2.07
K Factor:1.19
C90 Dynamic Load Rating1:19600 lb
C0 Static Load Rating:108600 lb
Fa-max Maximum Permissible Thrust Load2:5181 lb
Fr-max Maximum Allowable Slip Fit Radial Load3:16000 lb
Max. Speed4:1640 rpm
Note:Note: All units have a 1/8 pipe thread grease fittingThe Maximum Permissible Thrust Load applies to conditions of slip fit with set screw mounting or in applications where a large moment loading occur
