SKF 7322 BECBM image

Back to product page

SKF 7322 BECBM Characteristics

Number of Rows of Balls:Single Row
Precision Class:ABEC 3 | ISO P6
Maximum Capacity / Filling Slot:No
Snap Ring:No
Cage Material:Brass
Contact Angle:40 Degree
Internal Clearance:CC
Number of Bearings:1 (Single)
Mounting Arrangement:Universal
Inch - Metric:Metric
Long Description:90MM Bore; 160MM Outside Diameter; 30MM Width; Open; Yes Flush Ground; Ball Bearing; Single Row of Balls; ABEC 3 | ISO P6; No Filling Slot; No Snap Ring
Other Features:Axial Internal Clearance Greater Than Normal
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact
Manufacturer Item Number:7218 BECCM
Weight / LBS:5.32
d:90 mm
D:160 mm
B:30 mm
bore diameter::90 mm
radial static load capacity::96.5 kN
outside diameter::160 mm
outer ring width::30 mm
overall width::30 mm
maximum rpm::4800 RPM
contact angle::40 °
finish/coating::Uncoated
row type & fill slot::Single-Row Non-Fill Slot
precision rating::Not Rated
internal clearance::C0
fillet radius::2 mm
closure type::Open
series::72
radial dynamic load capacity::108 kN
d1 ≈:117.1 mm
d2 ≈:103.06 mm
D1 ≈:134.8 mm
a:67 mm
r1,2 min.:2 mm
r3,4 min.:1 mm
da min.:101 mm
Da max.:149 mm
Db max.:154 mm
ra max.:2 mm
rb max.:1 mm
Basic dynamic load rating C:116 kN
Basic static load rating C0:104 kN
Fatigue load limit Pu:4 kN
Reference speed:5000 r/min
Limiting speed:5000 r/min
Calculation factor A:0.149
Calculation factor kr:0.095
Calculation factor e:1.14
Calculation factor X:0.57
Calculation factor Y0:0.52
Calculation factor Y2:0.93
Calculation factor Y1:0.55
Mass bearing:2.3 kg
