SKF 3200 A-2RS1TN9 image

SKF 3200 A-2RS1TN9 Characteristics

d1:88.35 mm
D2:121.3 mm
r1,2 - min.:2.1 mm
da - min.:77 mm
Da - max.:128 mm
ra - max.:2 mm
Basic dynamic load rating - C:97.5 kN
Basic static load rating - C0:60 kN
Fatigue load limit - Pu:2.5 kN
Reference speed:10000 r/min
Limiting speed:6700 r/min
Calculation factor - kr:0.03
Calculation factor - f0:13.2
Category:Single Row Ball Bearing
Inventory:2.0
Minimum Buy Quantity:N/A
Weight / Kilogram:2.12
Product Group:B00308
Enclosure:Open
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:65MM Bore; 140MM Outside Diameter; 33MM Outer Race Diameter; Open; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6313
Weight / LBS:4.66
Outer Race Width:1.299 Inch | 33 Millimeter
Bore:2.559 Inch | 65 Millimeter
Outside Diameter:5.512 Inch | 140 Millimeter
d1 ≈:88.35 mm
D2 ≈:121.3 mm
r1,2 min.:2.1 mm
da min.:77 mm
Da max.:128 mm
ra max.:2 mm
Basic dynamic load rating C:97.5 kN
Basic static load rating C0:60 kN
Fatigue load limit Pu:2.5 kN
Calculation factor kr:0.03
Calculation factor f0:13.2
Mass bearing:2.11 kg
