FAG BEARING 7416-B-MP-UA Characteristics

Number of Rows of Balls:Double Row
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Snap Ring:No
Cage Material:Polyamide
Contact Angle:30 Degree
Internal Clearance:C0-Medium
Number of Bearings:1 (Single)
Inch - Metric:Metric
Long Description:50MM Bore; 90MM Outside Diameter; 30.2MM Width; Open; No Flush Ground; Ball Bearing; Double Row of Balls; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; C0-Medium; Polyamide Cage; 30 Degree; 1 (Singl
Other Features:Glass Fibre Reinforced Cage
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact
Manufacturer Item Number:3210 ATN9
Weight / LBS:1.5211
D:90 mm
d:50 mm
B:30.2 mm
bore diameter::50 mm
radial static load capacity::39 kN
outside diameter::90 mm
cage material::Polyamide
overall width::1.1875 in
outer ring width::30.2 mm
contact angle::30 °
maximum rpm::7000 RPM
row type & fill slot::Double-Row Non-Fill Slot
finish/coating::Uncoated
internal clearance::C0
precision rating::Not Rated
closure type::Open
fillet radius::1 mm
radial dynamic load capacity::51 kN
series::32
d2 ≈:57.8 mm
D2 ≈:82.1 mm
r1,2 min.:1.1 mm
a:52 mm
da min.:57 mm
Da max.:83 mm
ra max.:1 mm
Basic dynamic load rating C:51 kN
Basic static load rating C0:42.5 kN
Fatigue load limit Pu:1.8 kN
Reference speed:8000 r/min
Limiting speed:7000 r/min
Calculation factor kr:0.06
Calculation factor e:0.8
Calculation factor X:0.63
Calculation factor Y0:0.66
Calculation factor Y1:0.78
Calculation factor Y2:1.24
Mass bearing:0.65 kg
