5PCS F3-8M Axial Thrust Ball Bearing 3mm x 8mm 3.5mm F3-8M image

Back to product page

5PCS F3-8M Axial Thrust Ball Bearing 3mm x 8mm 3.5mm F3-8M Systems

d1:67.86 mm
d2:55.75 mm
D1:83.35 mm
a:45 mm
r1,2 - min.:1.5 mm
r3,4 - min.:2 mm
da - min.:55 mm
Da - max.:110 mm
Db - max.:97.5 mm
ra - max.:2 mm
rb - max.:2 mm
Basic dynamic load rating - C:70.2 kN
Basic static load rating - C0:45 kN
Fatigue load limit - Pu:1.9 kN
Reference speed:8000 r/min
Limiting speed:8000 r/min
Calculation factor - kr:0.1
Calculation factor - ka:1.6
Calculation factor - e:1.14
Calculation factor - X:0.35
Calculation factor - Y0:0.26
Calculation factor - Y1:0.55
Calculation factor - Y2:0.57
Category:Angular Contact Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:1.36
Product Group:B00308
Enclosure:Open
Flush Ground:Yes
Rolling Element:Ball Bearing
Number of Rows of Balls:Single Row
Precision Class:ABEC 3 | ISO P6
Maximum Capacity / Filling Slot:No
Snap Ring:No
Cage Material:Brass
Contact Angle:40 Degree
Internal Clearance:C0-Medium
Number of Bearings:1 (Single)
Preload:Medium
Mounting Arrangement:Universal
Inch - Metric:Metric
Long Description:40MM Bore; 110MM Outside Diameter; 27MM Width; Open; Yes Flush Ground; Ball Bearing; Single Row of Balls; ABEC 3 | ISO P6; No Filling Slot; No Snap Ring
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact
Manufacturer Item Number:7408 BGBM
Weight / LBS:2.998
Outside Diameter:4.331 Inch | 110 Millimeter
Bore:1.575 Inch | 40 Millimeter
Width:1.063 Inch | 27 Millimeter
bore diameter::40 mm
radial static load capacity::45 kN
outside diameter::110 mm
cage material::Brass
overall width::27 mm
outer ring width::27 mm
contact angle::40 °
maximum rpm::8000 RPM
row type & fill slot::Single-Row Non-Fill Slot
finish/coating::Uncoated
internal clearance::C0
precision rating::ABEC 3 (ISO Class 6)
closure type::Open
fillet radius::2 mm
radial dynamic load capacity::70.2 kN
series::74
d1 ≈:67.86 mm
d2 ≈:55.75 mm
D1 ≈:83.35 mm
r1,2 min.:1.5 mm
r3,4 min.:2 mm
da min.:55 mm
Da max.:110 mm
Db max.:97.5 mm
ra max.:2 mm
rb max.:2 mm
Basic dynamic load rating C:70.2 kN
Basic static load rating C0:45 kN
Fatigue load limit Pu:1.9 kN
Calculation factor A:0.0385
Calculation factor kr:0.1
Calculation factor e:1.14
Calculation factor X:0.57
Calculation factor Y0:0.52
Calculation factor Y2:0.93
Calculation factor Y1:0.55
Mass bearing:1.4 kg
