10PCS Miniature Roller Bearings 685ZZ-3 Size 5*11*3MM Mini bearing

✖

Home>Products>bearing>10PCS Miniature Roller Bearings 685ZZ-3 Size 5*11*3MM Mini bearing image

10PCS Miniature Roller Bearings 685ZZ-3 Size 5*11*3MM Mini bearing image

10PCS Miniature Roller Bearings 685ZZ-3 Size 5113MM Mini bearing Systems

Number of Rows of Balls:Single Row
Precision Class:ABEC 3 | ISO P6
Maximum Capacity / Filling Slot:No
Snap Ring:No
Cage Material:Brass
Contact Angle:35 Degree | 4 Point
Internal Clearance:C0-Medium
Number of Bearings:1 (Single)
Inch - Metric:Metric
Long Description:120MM Bore; 215MM Outside Diameter; 40MM Width; Open; No Flush Ground; Ball Bearing; Single Row of Balls; ABEC 3 | ISO P6; No Filling Slot; No Snap Ring
Other Features:Split Inner Race
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact
Manufacturer Item Number:QJ 224 N2MA
Weight / LBS:14.77
d:120 mm
D:215 mm
B:40 mm
inside diameter::120 mm
precision rating::ABEC 1 (ISO Class Normal)
outside diameter::215 mm
cage material::Brass
overall width::40 mm
maximum rpm::5000 RPM
internal clearance::C0
finish/coating::Uncoated
closure type::Open
outer ring width::40 mm
radial dynamic load capacity::300 kN
fillet radius::2 mm
radial static load capacity::365 kN
series::QJ
d1 ≈:152 mm
D1 ≈:183 mm
a:117 mm
h:11.7 mm
b:10.5 mm
r0:2 mm
r1,2 min.:2.1 mm
da min.:132 mm
Da max.:203 mm
ra max.:2 mm
Basic dynamic load rating C:300 kN
Basic static load rating C0:365 kN
Fatigue load limit Pu:12 kN
Limiting speed:5000 r/min
Calculation factor A:0.354
Calculation factor e:0.95
Calculation factor X:0.6
Calculation factor Y0:0.58
Calculation factor Y1:0.66
Calculation factor Y2:1.07
Mass bearing:6.95 kg
