CNC Linear Rail 12mm * 200mm Cylinder Shaft Optical Axis Smooth Rod Bar image

Back to product page

CNC Linear Rail 12mm * 200mm Cylinder Shaft Optical Axis Smooth Rod Bar Product identifiers

C:37,000 mm
Contact angle α:40 °
rs min:2.1 mm
r1s min:1.1 mm
Radial clearance class:CN
Mass:3.29 kg
Dynamic load, C:118 kN
Static load, C0:88.1 kN
Fatigue limit load, Cu:3.75 kN
Min operating temperature, Tmin:-40 °C
Max operating temperature, Tmax:120 °C
Characteristic cage frequency, FTF:0.41 Hz
Characteristic rolling element frequency, BSF:4.03 Hz
Characteristic outer ring frequency, BPF0:4.49 Hz
Characteristic inner ring frequency, BPFI:6.51 Hz
da min:361 mm
Da max:148 mm
Db max:153 mm
r1a max:1 mm
ra max:2 mm
Category:Angular Contact Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:3.3
Product Group:B00308
Enclosure:Open
Flush Ground:Yes
Rolling Element:Ball Bearing
Number of Rows of Balls:Single Row
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Snap Ring:No
Cage Material:Steel
Contact Angle:40 Degree
Internal Clearance:C0-Medium
Number of Bearings:1 (Single)
Mounting Arrangement:Universal
Inch - Metric:Metric
Long Description:65MM Bore; 160MM Outside Diameter; 37MM Width; Open; Yes Flush Ground; Ball Bearing; Single Row of Balls; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact
Manufacturer Item Number:7413BG
Weight / LBS:7.271
Outside Diameter:6.299 Inch | 160 Millimeter
Bore:2.559 Inch | 65 Millimeter
Width:1.457 Inch | 37 Millimeter
bore diameter::65 mm
radial static load capacity::88000 N
outside diameter::160 mm
operating temperature range::-40 to 120 ºC
overall width::37 mm
cage material::Brass
contact angle::40 °
outer ring width::37 mm
row type & fill slot::Single-Row Non-Fill Slot
maximum rpm::4400 rpm
internal clearance::C0
finish/coating::Uncoated
bore type::Round
precision rating::ISO Class 0
closure type::Open
fillet radius::2.1 mm
snap ring included::Without Snap Ring
series::74B
bearing material::High Carbon Chrome Steel
weight::3.290 kg
radial dynamic load capacity::118000 N
manufacturer product page::Click here
