WAHL 5 Star Detailer Tension Spring & Cam Follower image

Back to product page

WAHL 5 Star Detailer Tension Spring & Cam Follower Product identifiers

d1:94.3 mm
E:118.5 mm
r1,2 - min.:1.5 mm
r3,4 - min.:1.5 mm
s:1.2 mm
da - min.:84 mm
da - max.:116 mm
Da - min.:121 mm
Da - max.:122 mm
ra - max.:1.5 mm
rb - max.:1.5 mm
Basic dynamic load rating - C:150 kN
Basic static load rating - C0:156 kN
Fatigue load limit - Pu:20.4 kN
Reference speed:5600 r/min
Limiting speed:6000 r/min
Calculation factor - kr:0.12
Category:Cylindrical Roller Bearing
Inventory:1.0
Minimum Buy Quantity:N/A
Weight / Kilogram:1.254
Product Group:B04144
Bore Profile:Straight
Cage Material:Polymer
Precision Class:RBEC 1 | ISO P0
Number of Rows of Rollers:Single Row
Separable:Outer Ring - Both Sides
Rolling Element:Cylindrical Roller Bearing
Profile:Complete with Outer and Inner Ring
Snap Ring:No
Internal Clearance:C0-Medium
Retainer:Yes
Relubricatable:Yes
Inch - Metric:Metric
Other Features:High Capacity | 2 Rib Inner Ring | Plain Outer Ring | Cage on Inner Ring OD
Long Description:75MM Bore; Straight Bore Profile; 130MM Outside Diameter; 25MM Width; Polymer Cage Matetrial; RBEC 1 | ISO P0; Single Row; Outer Ring - Both Sides Separable; No Snap Ring; Relubricatable; C0-Medium In
UNSPSC:31171547
Harmonized Tariff Code:8482.50.00.00
Noun:Bearing
Manufacturer Item Number:N 215 ECP
Weight / LBS:2.762
Bore:2.953 Inch | 75 Millimeter
Outside Diameter:5.118 Inch | 130 Millimeter
Width:0.984 Inch | 25 Millimeter
bore diameter::75 mm
static load capacity::156 kN
outside diameter::130 mm
precision rating::Not Rated
overall width::25 mm
maximum rpm::6000 RPM
flanges::(2) Inner Ring
bearing material::Steel
bore type::Straight
cage material::Polyamide
number of rows::1
finish/coating::Uncoated
internal clearance::C0
closure type::Open
ring separation::Separable Ring
outer ring width::25 mm
operating temperature range::Maximum of +300 °F
fillet radius::1.5 mm
dynamic load capacity::150 kN
series::N2
d1 ≈:94.3 mm
r1,2 min.:1.5 mm
r3,4 min.:1.5 mm
s max.:1.2 mm
da min.:84 mm
da max.:116 mm
Da min.:121 mm
Da max.:122 mm
ra max.:1.5 mm
rb max.:1.5 mm
Basic dynamic load rating C:150 kN
Basic static load rating C0:156 kN
Fatigue load limit Pu:20.4 kN
Calculation factor kr:0.12
Limiting value e:0.2
Axial load factor Y:0.6
Mass bearing:1.22 kg
