Hiwin Tech 9812963004 6 X 6 Working Stroke Ball Screw

✖

Home>Products>HIWIN>Hiwin Tech 9812963004 6 X 6 Working Stroke Ball Screw image

Hiwin Tech 9812963004 6 X 6 Working Stroke Ball Screw image

Hiwin Tech 9812963004 6 X 6 Working Stroke Ball Screw Dimensions

Rolling Element:Spherical Roller Bearing
Housing Material:Cast Steel
Expansion / Non-expansion:Non-expansion
Mounting Bolts:3/4 Inch
Relubricatable:Yes
Insert Part Number:22218
Seals:Triple Lip Nitrile Rubber
Housing Configuration:1 Piece Solid
Pilot Configuration:With Pilot
Inch - Metric:Inch
Long Description:4 Bolt Round Flange Cartridge; 3-1/2" Bore; 8.6" Bolt Circle; 6.1" Bolt Spacing; 1 Piece Solid; Eccentric Collar Mount; Cast Steel; Spherical Roller Bearing; 4.03" Length Thru Bore
Other Features:Double Row
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Weight / LBS:32
Bolt Spacing:6.1 Inch | 154.9 Millimeter
Nominal Bolt Circle Diameter Round:8.6 Inch | 218.4 Millimeter
Cartridge Pilot Diameter:7.375 Inch | 187.32 Millimeter
Cartridge Pilot Depth:1.31 Inch | 33.274 Millimeter
d:3.5 Inch | 88.9 Millimeter
D:4.03 Inch | 102.362 Millimeter
