HYDRAULIC CAM FOLLOWER Mercedes Benz M Class ATV/MPV ML500 W164 5.0L - 306 BHP T Product identifiers

C:45 mm
r min.:3 mm
da min.:88 mm
Da max.:177 mm
ra max.:2,5 mm
Weight:5,72 Kg
Basic dynamic load rating (C):138 kN
Basic static load rating (C0):99 kN
(Grease) Lubrication Speed:3 800 r/min
(Oil) Lubrication Speed:4 500 r/min
rs min:3 mm
Radial clearance class:CN
Mass:5.72 kg
Dynamic load, C:138 kN
Static load, C0:99 kN
Fatigue limit load, Cu:3.9 kN
f0:12.7
Nlim (oil):4,500 rpm
Nlim (grease):3,800 rpm
Min operating temperature, Tmin:-20 °C
Max operating temperature, Tmax:120 °C
Characteristic cage frequency, FTF:0.37 Hz
Characteristic rolling element frequency, BSF:3.72 Hz
Characteristic outer ring frequency, BPF0:2.62 Hz
Characteristic inner ring frequency, BPFI:4.38 Hz
da min:88 mm
Da max:177 mm
ra max:2.5 mm
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:5.72
Product Group:B00308
Enclosure:Open
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:75MM Bore; 190MM Outside Diameter; 45MM Outer Race Diameter; Open; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6415
Weight / LBS:12.6
Outside Diameter:7.48 Inch | 190 Millimeter
Bore:2.953 Inch | 75 Millimeter
Outer Race Width:1.772 Inch | 45 Millimeter
bore diameter::75 mm
finish/coating::Uncoated
outside diameter::190 mm
bearing material::High Carbon Chrome Steel
overall width::45 mm
cage material::Steel
bore type::Round
inner ring width::45 mm
closure type::Open
outer ring width::45 mm
row type & fill slot::Single Row Non-Fill Slot
maximum rpm (grease)::3800 rpm
snap ring included::Without Snap Ring
maximum rpm (oil)::4500 rpm
internal clearance::CN
fillet radius::3 mm
operating temperature range::-40 to 120 ºC
maximum rpm::4500 RPM
dynamic load capacity::138000 N
series::64
static load capacity::99000 N
manufacturer product page::Click here
precision rating::Class 0
