SUZUKI GSXR750 J 88 SLINGSHOT OEM SPEC NSK SPROCKET CARRIER BEARING & SEAL KIT

✖

Home>Products>nsk bearing>SUZUKI GSXR750 J 88 SLINGSHOT OEM SPEC NSK SPROCKET CARRIER BEARING & SEAL KIT image

SUZUKI GSXR750 J 88 SLINGSHOT OEM SPEC NSK SPROCKET CARRIER BEARING & SEAL KIT image

SUZUKI GSXR750 J 88 SLINGSHOT OEM SPEC NSK SPROCKET CARRIER BEARING & SEAL KIT Code system

Cage Material:Polyamide
Precision Class:ABEC 1 | ISO P0
Internal Clearance:C0-Medium
Number of Rows of Balls:Double Row
Other Features:Allowable Misalignment 3 Deg
Long Description:8MM Bore; Shaft Mount; 22MM Outside Diameter; 7MM Inner Race Width; 7MM Outer Race Width; Open; Polyamide Cage; Double Row of Balls; ABEC 1 | ISO P0; C0-Medium
Inch - Metric:Metric
UNSPSC:31171532
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Self Aligning
Manufacturer Item Number:108 TN9
Weight / LBS:0.031
D:22 mm
Inner Race Width:0.276 Inch | 7 Millimeter
d:8 mm
Outer Race Width:0.276 Inch | 7 Millimeter
bore diameter::8 mm
precision rating::Not Rated
outside diameter::22 mm
maximum rpm::40000 RPM
overall width::7 mm
cage material::Fiberglass Reinforced Nylon
bore type::Straight
finish/coating::Uncoated
closure type::Open
maximum misalignment::3 °
internal clearance::C0
outer ring width::7 mm
dynamic load capacity::2.65 kN
fillet radius::0.3 mm
static load capacity::0.56 kN
series::100
B:7 mm
d1 ≈:12.709 mm
D1 ≈:17.6 mm
r1,2 min.:0.3 mm
da min.:10.4 mm
Da max.:19.6 mm
ra max.:0.3 mm
Basic dynamic load rating C:2.65 kN
Basic static load rating C0:0.56 kN
Fatigue load limit Pu:0.029 kN
Reference speed:60000 r/min
Limiting speed:40000 r/min
Permissible angular misalignment α:3 °
Calculation factor kr:0.03
Calculation factor e:0.33
Calculation factor Y0:2
Calculation factor Y1:1.9
Calculation factor Y2:3
Mass bearing:0.014 kg
