Main Bearing, D/S,Triumph Unit 650/750 1963-1979 & P-Unit, 70-2879 CN, RHP

✖

Home>Products>rhp bearing>Main Bearing, D/S,Triumph Unit 650/750 1963-1979 & P-Unit, 70-2879 CN, RHP image

Main Bearing, D/S,Triumph Unit 650/750 1963-1979 & P-Unit, 70-2879 CN, RHP image

Main Bearing, D/S,Triumph Unit 650/750 1963-1979 & P-Unit, 70-2879 CN, RHP Compare similar products

Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Contact Seal
Internal Clearance:C3-Loose
Inch - Metric:Metric
Long Description:25MM Bore; 47MM Outside Diameter; 12MM Outer Race Diameter; 1 Seal; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6005 RSJEM
Weight / LBS:0.19
d:0.984 Inch | 25 Millimeter
D:1.85 Inch | 47 Millimeter
Outer Race Width:0.472 Inch | 12 Millimeter
bore diameter::25 mm
static load capacity::6.55 kN
outside diameter::47 mm
precision rating::ABEC 3 (ISO Class 6)
overall width::12 mm
finish/coating::Uncoated
bore type::Round
cage material::Steel
closure type::Single Seal
outer ring width::12 mm
row type & fill slot::Single Row Non-Fill Slot
fillet radius::0.6 mm
internal clearance::C3
maximum rpm::16000 RPM
operating temperature range::-40 to +210 °F
series::60
dynamic load capacity::11.9 kN
