THK GROUND Ball Screw SX 14-02 L215mm ROUTER/CNC/nsk

✖

Home>Products>Thk>THK GROUND Ball Screw SX 14-02 L215mm ROUTER/CNC/nsk image

THK GROUND Ball Screw SX 14-02 L215mm ROUTER/CNC/nsk image

THK GROUND Ball Screw SX 14-02 L215mm ROUTER/CNC/nsk Code system

C:34 mm
r min.:2.1 mm
da min.:112 mm
Da max.:168 mm
ra max.:2.0 mm
Weight:3.14 Kg
Basic dynamic load rating (C):122 kN
Basic static load rating (C0):93 kN
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Product Group:B00308
Enclosure:2 Seals
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Contact Seal
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:100MM Bore; 180MM Outside Diameter; 34MM Outer Race Width; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Steel Cage
Other Features:Deep Groove | Rubber Seal
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Inner Race Width:0 Inch | 0 Millimeter
Bore:3.937 Inch | 100 Millimeter
Outside Diameter:7.087 Inch | 180 Millimeter
Outer Race Width:1.339 Inch | 34 Millimeter
Bore Type:Cylindrical Bore
Configuration:Single Row
Bore Size:100 mm
Width:34 mm
Fillet Radius/Chamfer:2.1 mm
Dynamic Load Rating:122,000 N
Static Load Rating:93,000 N
Limiting Speed - Grease:2,400 rpm
Factor fo:14.4
Radial Clearance:0.012 to 0.036 mm
da (min):112 mm
Da (max):168 mm
ra (max):2 mm
