THK / SMC XY Pneumatic Stage w/ 300mm Rails 100mm Rails SR15V & SR15W Blocks ++

✖

Home>Products>Thk>THK / SMC XY Pneumatic Stage w/ 300mm Rails 100mm Rails SR15V & SR15W Blocks ++ image

THK / SMC XY Pneumatic Stage w/ 300mm Rails 100mm Rails SR15V & SR15W Blocks ++ image

THK / SMC XY Pneumatic Stage w/ 300mm Rails 100mm Rails SR15V & SR15W Blocks ++ Code system

Rolling Element:Ball Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Non-expansion
Mounting Bolts:3/4 Inch
Relubricatable:Yes
Insert Part Number:INS-SCM-300-HT
Seals:Single Lip Contact
Housing Configuration:1 Piece Solid
Pilot Configuration:No Pilot
Inch - Metric:Inch
Long Description:4 Bolt Square Flange Block; 3" Bore; 8-1/2" Bolt Circle; 6" Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 2-11/32" Length Thru Bore; Relubricatable; Single
Other Features:Single Row | Medium Duty | Wide Inner Race | High Temperature Range From 225 to 400 Degree F
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.40
Noun:Bearing
Keyword String:Flanged
Manufacturer Item Number:F4B-SCM-300-HT
Manufacturer Internal Number:059696
Weight / LBS:21.2
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
Nominal Bolt Circle Diameter Round:8.5 Inch | 215 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
d:3 Inch | 76.2 Millimeter
Bolt Spacing:6 Inch | 152.4 Millimeter
D:2.344 Inch | 59.538 Millimeter
