SKF ROLLER BEARINGS CONE P/N 07100 7JF (2996) - Leader Industrial Manufacture

✖

Home>Products>skf bearing>SKF ROLLER BEARINGS CONE P/N 07100 7JF (2996) image

SKF ROLLER BEARINGS CONE P/N 07100 7JF (2996) image

SKF ROLLER BEARINGS CONE P/N 07100 7JF (2996) Product Features

Bore Profile:Tapered
Cage Material:Bronze
Enclosure:Open
Number of Rows of Rollers:Double Row
Relubricatable:Yes
Withdrawal Sleeve:AH3276 (Specify bore)
Inch - Metric:Metric
Long Description:380MM Tapered Bore; 680MM Outside Diameter; 240MM Width; C3-Loose Clearance; Adapter Mount; Double Row of Spherical Roller Bearings; Bronze Cage Material; Open Enclosure; Relubricatable; Adapter Part
Other Features:Order adapter or withdrawal sleeve or nut separately. Others may be available
UNSPSC:31171510
Harmonized Tariff Code:8482.30.80.00
Noun:Bearing
Keyword String:Spherical
Manufacturer Item Number:23276 KYMBW906AC3
Weight / LBS:809.7
D:26.772 Inch | 680 Millimeter
d:14.961 Inch | 380 Millimeter
Adapter Part Number:SNP3276 (Specify bore) Inch | H3276 (Specify bore) Millimeter
B:9.449 Inch | 240 Millimeter
Design Unit:METRIC
Bore Taper:1/12
Bearing Weight:379.400 Kg
Cage Type:YMB
UPC Code:087796178144
d - Bore:380.000 mm
D - Outer Diameter:680.000 mm
B - Inner Ring Width:240 mm
B - Outer Ring Width:240.000 mm
R - Inner Ring To Clear Radius1:5.000 mm
r - Outer Ring To Clear Radius2:5.000 mm
da - Inner Ring Backing Diameter:442.000 mm
Da - Outer Ring Backing Diameter:611.000 mm
C0 - Static Radial Rating:9520000 N
C1(2) - Dynamic Radial Rating (Two-Rows):5970000 N
e - ISO Factor3:0.34
Y0 - ISO Factor4:1.98
Y1 - ISO Factor5:2.95
Y2 - ISO Factor6:1.94
Reference Thermal Speed Rating (Grease):390
Reference Thermal Speed Rating (Oil)7:420
Cg - Geometry Factor8:0.0919
