Timken 516008 Wheel Bearing - Leader Industrial Manufacture

✖

Home>Products>timken bearing>Timken 516008 Wheel Bearing image

Timken 516008 Wheel Bearing image

Timken 516008 Wheel Bearing Sponsored Products Related To This Item

Rolling Element:Spherical Plain
Material - Outer Member:Steel
Material - Ball:Steel
Material - Liner:Steel
Relubricatable:No
Enclosure:Open
Other Features:3 Piece | Zinc Plated Outer
Long Description:8MM Bore; 6.5MM House Width; Female Stud Profile; M8 X 1.25; Left Hand Thread Direction; Spherical Plain Bearing; Steel Outer Member; Steel Ball; Stee
Inch - Metric:Metric
UNSPSC:31171508
Harmonized Tariff Code:8483.30.80.55
Noun:Bearing
Keyword 3:Rod End
Keyword String:Plain Spherical Rod End
Manufacturer Item Number:SIL 8 E
Weight / LBS:0.079
d:8 mm
Housing Width:0.256 Inch | 6.5 Millimeter
Ball Width:0.315 Inch | 8 Millimeter
bore diameter::8 mm
ball material::Steel
misalignment angle::15 °
race material::Steel
shank thread length::15 mm
radial static load capacity::12.9 kN
rod end type::Female Threaded
operating temperature range::-50 to +300 °C
shank thread size::M8
head diameter::25 mm
thread direction::Left Hand
head width::6.5 mm
grade::Commercial/Industrial
ball width::8 mm
lubrication type::No Fitting
length to ball center::36 mm
housing material::Zinc-Plated Steel
d2 max.:25 mm
B:8 mm
G:M 8
C1 max.:6.5 mm
h1:36 mm
α:15 °
dk:13 mm
d4 ≈:13 mm
l3 min.:15 mm
l4 max.:50 mm
l5 ≈:9 mm
l7 min.:11 mm
w:11 mm
r1 min.:0.3 mm
Basic dynamic load rating C:5.5 kN
Basic static load rating C0:12.9 kN
Specific dynamic load factor K:100 N/mm²
Material constant KM:330
Mass rod end:0.039 kg
