Timken 510060 Wheel Bearing image

Back to product page

Timken 510060 Wheel Bearing Sponsored Products Related To This Item

C:29 mm
r min.:2 mm
da min.:54 mm
Da max.:111 mm
ra max.:2 mm
Weight:1,53 Kg
Basic dynamic load rating (C):77 kN
Basic static load rating (C0):45 kN
(Grease) Lubrication Speed:6 300 r/min
(Oil) Lubrication Speed:7 400 r/min
rs min:2 mm
Radial clearance class:CN
Mass:1.53 kg
Dynamic load, C:77 kN
Static load, C0:45 kN
Fatigue limit load, Cu:2.05 kN
f0:12.1
Nlim (oil):7,400 rpm
Nlim (grease):6,300 rpm
Min operating temperature, Tmin:-20 °C
Max operating temperature, Tmax:120 °C
Characteristic cage frequency, FTF:0.36 Hz
Characteristic rolling element frequency, BSF:3.33 Hz
Characteristic outer ring frequency, BPF0:2.53 Hz
Characteristic inner ring frequency, BPFI:4.47 Hz
da min:54 mm
Da max:111 mm
ra max:2 mm
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:1.54
Product Group:B00308
Enclosure:Open
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:45MM Bore; 120MM Outside Diameter; 29MM Outer Race Diameter; Open; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6409
Weight / LBS:3.381
Bore:1.772 Inch | 45 Millimeter
Outside Diameter:4.724 Inch | 120 Millimeter
Outer Race Width:1.142 Inch | 29 Millimeter
bore diameter::45 mm
precision rating::Class 0
outside diameter::120 mm
finish/coating::Uncoated
overall width::29 mm
bearing material::High Carbon Chrome Steel
bore type::Round
cage material::Steel
closure type::Open
inner ring width::29 mm
row type & fill slot::Single Row Non-Fill Slot
outer ring width::29 mm
snap ring included::Without Snap Ring
maximum rpm (grease)::6300 rpm
internal clearance::CN
maximum rpm (oil)::7400 rpm
operating temperature range::-40 to 120 ºC
fillet radius::2 mm
dynamic load capacity::77000 N
manufacturer product page::Click here
static load capacity::45000 N
