Timken 352 Bearing (9G) - Leader Industrial Manufacture

✖

Home>Products>timken bearing>Timken 352 Bearing (9G) image

Timken 352 Bearing (9G) image

Timken 352 Bearing (9G) Sponsored Products Related To This Item

Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Non-Contact Seal
Internal Clearance:C3-Loose
Inch - Metric:Metric
Long Description:20MM Bore; 42MM Outside Diameter; 12MM Outer Race Width; 2 Seals; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C3-Loose Internal Clearance; Steel Cage; N
Other Features:Deep Groove | Non-Friction Nitrile Rubber Seal | Electric Motor Grade
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:6004LLBC3/EM
Weight / LBS:0.15
D:1.654 Inch | 42 Millimeter
d:0.787 Inch | 20 Millimeter
Inner Race Width:0 Inch | 0 Millimeter
Outer Race Width:0.472 Inch | 12 Millimeter
bore diameter::20 mm
precision rating::ISO Class 0
outside diameter::42 mm
finish/coating::Uncoated
overall width::12 mm
bearing material::High Carbon Chrome Steel
bore type::Round
cage material::Steel
closure type::Double Sealed
inner ring width::12 mm
row type & fill slot::Single Row Non-Fill Slot
outer ring width::12 mm
snap ring included::Without Snap Ring
maximum rpm (grease)::18000 rpm
internal clearance::C3
fillet radius::0.6 mm
operating temperature range::-40 to 120 ºC
maximum rpm::21000 RPM
dynamic load capacity::9400 N
series::60
static load capacity::5050 N
