SKF BEARING LUBRICATOR CNP 2 / 787 95 TR / HMV 33 A

✖

Home>Products>skf bearing>SKF BEARING LUBRICATOR CNP 2 / 787 95 TR / HMV 33 A image

SKF BEARING LUBRICATOR CNP 2 / 787 95 TR / HMV 33 A image

SKF BEARING LUBRICATOR CNP 2 / 787 95 TR / HMV 33 A Product Features

Rolling Element:Cylindrical Roller Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Expansion
Mounting Bolts:30 Millimeter
Relubricatable:Yes
Insert Part Number:MSM280BX
Seals:Triple Lip Labyrinth
Housing Configuration:2 Piece Split
Inch - Metric:Metric
Other Features:Single Row | Medium Duty | With Support | Wide Inner Ring | Minimum Actual Bolt Center to Center 534 MM
UNSPSC:31171511
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Pillow Block
Weight / LBS:1,148.4
D:7.323 Inch | 186 Millimeter
Bolt Spacing Maximum:0 Inch | 0Millimeter
Actual Bolt Center to Center:29 Inch | 736Millimeter
B:14.882 Inch | 378 Millimeter
Nominal Bolt Center to Center:29 Inch | 736 Millimeter
d:11.024 Inch | 280 Millimeter
Bolt Spacing Minimum:0 Inch | 0Millimeter
Shaft Size:280 mm
Seal Type:Aluminium Triple Labyrinth
Bearing Type:Split Cylindrical Expansion Type
Support Type:Eight-Bolt Plummer Block
Series Type:Medium Series
Pillow/Plummer Block Style:Split Cylindrical Housed Unit - Standard
Bolt Size:8 x M30
Bearing Number:MSM280BX
Dimension H:14.882 in
Dimension H1:2.4 in
Dimension H2:29.9 in
Dimension J1:29.0 in
Dimension J2:21.0 in
Dimension K:10.0 in
Dimension L:36.0 in
Dimension M:13.0 in
Housing Width:11.8 in
Cr - Dynamic Load Rating:331818 lbf
Cor - Static Load Rating:529875 lbf
Maximum Speed:670 rpm
Note:This product line was formerly known as “Revolvo”
