5-SKF-Bearing,#LBCR 12, T49,Free shipping lower 48, 30 day warranty!

✖

Home>Products>skf bearing>5-SKF-Bearing,#LBCR 12, T49,Free shipping lower 48, 30 day warranty! image

5-SKF-Bearing,#LBCR 12, T49,Free shipping lower 48, 30 day warranty! image

5-SKF-Bearing,#LBCR 12, T49,Free shipping lower 48, 30 day warranty! Product Features

Rolling Element:Cylindrical Roller Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Expansion
Mounting Bolts:24 Millimeter
Relubricatable:Yes
Insert Part Number:MSE507BX
Seals:Triple Lip Labyrinth
Housing Configuration:2 Piece Split
Pilot Configuration:No Pilot
Inch - Metric:Inch
Long Description:4 Bolt Round Flange Block; 5-7/16" Bore; 17-1/2" Bolt Circle; 2 Piece Split; Clamp Collar Mount; Cast Iron; Cylindrical Roller Bearing; 4.626" Length Thru Bore; 12.4" Bolt Spacing;
Other Features:Single Row | Wide Inner Ring | Medium Duty
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Weight / LBS:263.43
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
Nominal Bolt Circle Diameter Round:17.5 Inch | 444 Millimeter
d:5.438 Inch | 138.125 Millimeter
Bolt Spacing:12.4 Inch | 314 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
D:4.626 Inch | 117.5 Millimeter
Shaft Size:5-7/16 in
Seal Type:Aluminium Triple Labyrinth
Bearing Type:Split Cylindrical Expansion Type
Support Type:Round Flange
Series Type:Medium Series
Bolt Size:4 x M24
Bearing Number:MSE507BX
Bearing - Housing - Seal:MSE507BXHATL
Bearing - Housing - Seal UPC:013992042675
Bearing UPC:013992032805
Dimension T:20.0 in
Dimension R:17.5 in
Dimension P:1.0 in
Dimension H:4.5 in
Dimension N:14.875 in
Dimension V:0.1 in
Dimension L:8.2 in
Cr - Dynamic Load Rating:134885 lbf
Cor - Static Load Rating:183669 lbf
Maximum Speed:1450 rpm
Note:This product line was formerly known as “Revolvo”
