SNR Wheel Bearing Kit R15858 - Leader Industrial Manufacture

✖

Home>Products>snr bearing>SNR Wheel Bearing Kit R15858 image

SNR Wheel Bearing Kit R15858 image

SNR Wheel Bearing Kit R15858 Systems

Rolling Element:Cylindrical Roller Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Expansion
Mounting Bolts:30 Millimeter
Relubricatable:Yes
Insert Part Number:MSE607BX
Seals:Triple Lip Labyrinth
Housing Configuration:2 Piece Split
Pilot Configuration:No Pilot
Inch - Metric:Inch
Long Description:4 Bolt Round Flange Block; 6-7/16" Bore; 20" Bolt Circle; 2 Piece Split; Clamp Collar Mount; Cast Iron; Cylindrical Roller Bearing; 5.512" Length Thru Bore; 14.1" Bolt Spacing; Rel
Other Features:Single Row | Wide Inner Ring | Medium Duty
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Weight / LBS:351.82
Nominal Bolt Circle Diameter Round:20 Inch | 508 Millimeter
Bolt Spacing:14.1 Inch | 359.2 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
d:6.438 Inch | 163.525 Millimeter
D:5.512 Inch | 140 Millimeter
Shaft Size:6-7/16 in
Seal Type:Aluminium Triple Labyrinth
Bearing Type:Split Cylindrical Expansion Type
Support Type:Round Flange
Series Type:Medium Series
Bolt Size:4 x M30
Bearing Number:MSE607BX
Bearing - Housing - Seal:MSE607BXHATL
Bearing - Housing - Seal UPC:013992043573
Bearing UPC:013992039699
Dimension T:23.0 in
Dimension R:20.0 in
Dimension P:1.1 in
Dimension H:4.9 in
Dimension N:16.875 in
Dimension V:0.2 in
Dimension L:9.0 in
Cr - Dynamic Load Rating:189289 lbf
Cor - Static Load Rating:264151 lbf
Maximum Speed:1200 rpm
Note:This product line was formerly known as “Revolvo”
