SKF 3214 E-ZNR New In Box Product Features

Mounting Method:Eccentric Collar
Rolling Element:Ball Bearing
Relubricatable:No
Seal Type:Double Land Riding Rubber Contact
Snap Ring:No
Inch - Metric:Inch
Long Description:1-15/16" Bore; Narrow Inner Ring; 0.866" Outer Race Width; Cylindrical Outer Race Profile; 3.543" Outside Diameter; Eccentric Collar; Ball Bearing; 1.719" Length Thru Bore; No Relu
Other Features:Single Row | Standard Duty
Outer Race Width:0.866 Inch | 21.996 Millimeter
D:1.719 Inch | 43.663 Millimeter
d:1.938 Inch | 49.225 Millimeter
Shaft Size d:1 15/16 in
Bore Type:Cylindrical bore
Bearing Type:Ball Bearing
Material:Bearing Steel
Lubrication Type:Non-Relubricatable
O.D. Type:Cylindrical OD
Dimension B2:0.720 in
Series:Standard
Sub Series:RA..RR
Outside Diameter D:3.543 in
Inner Ring Width B:30.18 mm
Outside Ring Width C:22.000 mm
Radius r:0.6 mm
Center of Bearing from End S:11 mm
Dimension S1:32.7 mm
Set Screw Size:3/8-16
Number of Set Screws:2
Angle between Set Screws:90 º
Dimension B1:1.72 in
Static Load Rating:5210 lbf
Dynamic Load Rating:8740 lbf
