XLJ 4.1/2 SIGMA 114.3x158.75x22.23mm B 22.23 mm Deep groove ball bearings

✖

Home>Products>Deep groove ball bearings>XLJ 4.1/2 SIGMA 114.3x158.75x22.23mm B 22.23 mm Deep groove ball bearings image

XLJ 4.1/2 SIGMA 114.3x158.75x22.23mm B 22.23 mm Deep groove ball bearings image

XLJ 4.1/2 SIGMA 114.3x158.75x22.23mm B 22.23 mm Deep groove ball bearings Dimensions

C:37,000 mm
rs min:2.1 mm
Radial clearance class:CN
Mass:3.02 kg
Dynamic load, C:113 kN
Static load, C0:77 kN
Fatigue limit load, Cu:3.25 kN
f0:13.2
Nlim (grease):2,900 rpm
Min operating temperature, Tmin:-25 °C
Max operating temperature, Tmax:110 °C
Characteristic cage frequency, FTF:0.38 Hz
Characteristic rolling element frequency, BSF:4.12 Hz
Characteristic outer ring frequency, BPF0:3.08 Hz
Characteristic inner ring frequency, BPFI:4.92 Hz
da min:86 mm
da max:99 mm
Da max:149 mm
ra max:2 mm
Category:Single Row Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:3.01
Product Group:B00308
Enclosure:1 Seal
Precision Class:ABEC 1 | ISO P0
Maximum Capacity / Filling Slot:No
Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Enclosure Type:Contact Seal
Internal Clearance:C0-Medium
Inch - Metric:Metric
Long Description:75MM Bore; 160MM Outside Diameter; 37MM Outer Race Width; 1 Seal; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features; C0-Medium Internal Clearance; Steel Cage;
Other Features:Deep Groove | Double Lip Friction Nitrile Rubber Seal | -20 To 120 Deg C
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Weight / LBS:6.87842
Inner Race Width:0 Inch | 0 Millimeter
Bore:2.953 Inch | 75 Millimeter
Outside Diameter:6.299 Inch | 160 Millimeter
Outer Race Width:1.457 Inch | 37 Millimeter
