1635-2RS CYSD B 12.7 mm 19.05x44.45x12.7mm Deep groove ball bearings image

Back to product page

1635-2RS CYSD B 12.7 mm 19.05x44.45x12.7mm Deep groove ball bearings Dimensions

d1:52.65 mm
d2:43.62 mm
D1:63.45 mm
a:35 mm
r1,2 - min.:1.5 mm
r3,4 - min.:1 mm
da - min.:44 mm
Da - max.:71 mm
Db - max.:74.4 mm
ra - max.:1.5 mm
rb - max.:1 mm
Basic dynamic load rating - C:39 kN
Basic static load rating - C0:24.5 kN
Fatigue load limit - Pu:1 kN
Reference speed:10000 r/min
Limiting speed:10000 r/min
Calculation factor - kr:0.1
Calculation factor - ka:1.6
Calculation factor - e:1.14
Calculation factor - X:0.35
Calculation factor - Y0:0.26
Calculation factor - Y1:0.55
Calculation factor - Y2:0.57
Category:Angular Contact Ball Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:0.47
Product Group:B00308
Enclosure:Open
Flush Ground:Yes
Rolling Element:Ball Bearing
Number of Rows of Balls:Single Row
Precision Class:ABEC 3 | ISO P6
Maximum Capacity / Filling Slot:No
Snap Ring:No
Cage Material:Brass
Contact Angle:40 Degree
Internal Clearance:CB
Number of Bearings:1 (Single)
Mounting Arrangement:Universal
Inch - Metric:Metric
Long Description:35MM Bore; 80MM Outside Diameter; 21MM Width; Open; Yes Flush Ground; Ball Bearing; Single Row of Balls; ABEC 3 | ISO P6; No Filling Slot; No Snap Ring
Other Features:Normal Axial Internal Clearance
UNSPSC:31171531
Harmonized Tariff Code:8482.10.50.28
Noun:Bearing
Keyword String:Angular Contact
Manufacturer Item Number:7307 BECBY
Weight / LBS:1.032
Bore:1.378 Inch | 35 Millimeter
Width:0.827 Inch | 21 Millimeter
Outside Diameter:3.15 Inch | 80 Millimeter
bore diameter::35 mm
radial static load capacity::24.5 kN
outside diameter::80 mm
cage material::Brass
overall width::21 mm
outer ring width::21 mm
contact angle::40 °
maximum rpm::10000 RPM
row type & fill slot::Single-Row Non-Fill Slot
finish/coating::Uncoated
internal clearance::C0
precision rating::ABEC 3 (ISO Class 6)
closure type::Open
fillet radius::1.5 mm
radial dynamic load capacity::39 kN
series::73
d1 ≈:52.5 mm
d2 ≈:43.62 mm
D1 ≈:63.45 mm
r1,2 min.:1.5 mm
r3,4 min.:1 mm
da min.:44 mm
Da max.:71 mm
Db max.:74.4 mm
ra max.:1.5 mm
rb max.:1 mm
Basic dynamic load rating C:41.5 kN
Basic static load rating C0:26.5 kN
Fatigue load limit Pu:1.14 kN
Calculation factor A:0.0111
Calculation factor kr:0.1
Calculation factor e:1.14
Calculation factor X:0.57
Calculation factor Y0:0.52
Calculation factor Y2:0.93
Calculation factor Y1:0.55
Mass bearing:0.45 kg
