AST090 22070 AST ID Chamfer Angle (B deg.) 45 Plain bearings Product Features

Rolling Element:Ball Bearing
Snap Ring:No
Internal Special Features:No
Cage Material:Steel
Internal Clearance:C3-Loose
Inch - Metric:Metric
Long Description:40MM Bore; 80MM Outside Diameter; 18MM Outer Race Diameter; Open; Ball Bearing; ABEC 1 | ISO P0; No Filling Slot; No Snap Ring; No Internal Special Features
UNSPSC:31171504
Harmonized Tariff Code:8482.10.50.68
Noun:Bearing
Keyword String:Ball
Manufacturer Item Number:208K
Weight / LBS:0.83
d:1.575 Inch | 40 Millimeter
D:3.15 Inch | 80 Millimeter
Outer Race Width:0.709 Inch | 18 Millimeter
Design Units:METRIC
Ball Type:STEEL
Bearing Weight:0.376 Kg
d - Bore:40 mm
D - Outer Diameter:80 mm
Bearing Width:18 mm
do - Ball Diameter:12.700 mm
Ce - Dynamic Radial Rating1:36200 N
C0 - Static Radial Rating:19800 N
Limiting Speed (Grease):5000 rpm
Limiting Speed (Oil):5830 rpm
R - Inner Ring To Clear Radius2:1.1 mm
r - Outer Ring To Clear Radius3:1.1 mm
da - Inner Ring Backing Diameter:43.900 mm
Da - Outer Ring Backing Diameter:72.900 mm
