BLP205-16 FYH Basic static load rating (C0) 7.85 kN Bearing units

✖

Home>Products>Bearing units>BLP205-16 FYH Basic static load rating (C0) 7.85 kN Bearing units image

BLP205-16 FYH Basic static load rating (C0) 7.85 kN Bearing units image

BLP205-16 FYH Basic static load rating (C0) 7.85 kN Bearing units specification

Rolling Element:Ball Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Non-expansion
Relubricatable:Yes
Insert Part Number:A-UC206-104D1
Seals:Single Lip Land Riding
Housing Configuration:1 Piece Solid
Pilot Configuration:No Pilot
Inch - Metric:Inch
Long Description:4 Bolt Square Flange Block; 1-1/4" Bore; 4.7" Bolt Circle; 3-1/4" Bolt Spacing; 1 Piece Solid; Set Screw Mount; Cast Iron; Ball Bearing; 1-1/2" Length Thru Bore; Relubricatable; Si
Other Features:Single Row | Wide Inner Race | Has Flinger
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.40
Noun:Bearing
Keyword String:Flanged
Manufacturer Item Number:UCFU-1.1/4S
Weight / LBS:0.002
D:1.5 Inch | 38.1 Millimeter
Nominal Bolt Circle Diameter Round:4.7 Inch | 120 Millimeter
Bolt Spacing:3.25 Inch | 82.55 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
d:1.25 Inch | 31.75 Millimeter
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
bore diameter::1.2500 in
expansion type::Non-Expansion Bearing (Fixed)
bolt center-to-center length::3.2500 in
seal type::Contact with Flinger
overall length/diameter::4.6563 in
length through bore::1-53/64 in
bore type::Round
finish/coating::Uncoated
duty type::Standard Duty
lubrication type::Lubrication Fitting
mounting type::Four-Bolt Flange
series::UCFU
housing material::Cast Iron
standards met::ISO, AFBMA
locking device::Set Screw
replacement bearing::A-UC207-104D1
