SKF CBF100ZM

SKF CBF100ZM SPECIFICATIONS

SKF CBF100ZM, Units and Housings CAD models , 0.0 Inventory Mounted Units Manufacturing Service . Get Your Free. Take Up Units Category
Category:Take Up Units
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:17.252
Product Group:M06288
Component Description:Take Up Bearing Only
Rolling Element:Spherical Roller Bearing
Housing Style:Unit Only

Download SKF CBF100ZM Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

Information techniques SKF CBF100ZM

Mounting Method:V Lock
Compatible Take Up Frame:QMTF
Insert Part Number:22219
Housing Material:Cast Steel
Other Features:Double Row | Single Nut | Expansion | Two Lip Viton Seal | Steel Cage
Inch - Metric:Inch
Long Description:Take Up Bearing Only; 3-7/16" Bore; 1-13/16" Slot Width; 6-13/16" Slot to Slot Distance; Spherical Roller Bearing; Unit Only; V Lock Mount; QMTF Take Up Frame; 22219 Insert Part; Cast S
UNSPSC:31171533
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Take Up
Weight / LBS:44
Slot to Slot Distance:6.813 Inch | 173.05 Millimeter
Slot Width:1.813 Inch | 46.05 Millimeter
d:3.438 Inch | 87.325 Millimeter
