SKF FYR 1.7/16 H-3

SKF FYR 1.7/16 H-3 SPECIFICATIONS

What are the dimensions of 80x140x26 a SKF FYR 1.7/16 H-3? Mounted Units Manufacturing 80 Bore Diameter (mm) Service . Get Your Free, Instant 80x140x26 Size (mm) Quote‎！
Bearing number:NJ216
Size (mm):80x140x26
Bore Diameter (mm):80
Outer Diameter (mm):140
Width (mm):26
d:80 mm
Fw:95,3 mm
D:140 mm

Download SKF FYR 1.7/16 H-3 Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

Information techniques SKF FYR 1.7/16 H-3

B:26 mm
C:26 mm
r min.:2 mm
r1 min.:2 mm
J:101,2 mm
Weight:1,5 Kg
Basic dynamic load rating (C):106 kN
Basic static load rating (C0):122 kN
(Grease) Lubrication Speed:4 800 r/min
E:125.3 mm
F:95.3 mm
d1:101.2 mm
rs min:2 mm
r1s min:2 mm
Radial clearance class:CN
Mass (without HJ ring):1.52 kg
Dynamic load, C:106 kN
Static load, C0:122 kN
Fatigue limit load, Cu:14.5 kN
Nlim (oil):5,700 rpm
Nlim (grease):4,800 rpm
Min operating temperature, Tmin:-40 °C
Max operating temperature, Tmax:120 °C
da min:89 mm
da max:94 mm
dc min:104 mm
Da max:131 mm
ra max:2 mm
Category:Cylindrical Roller Bearing
Inventory:0.0
Minimum Buy Quantity:N/A
Weight / Kilogram:1.53
Product Group:B04144
Bore Profile:Straight
Cage Material:Steel
Precision Class:RBEC 1 | ISO P0
Number of Rows of Rollers:Single Row
Separable:Inner Ring - One Side
Rolling Element:Cylindrical Roller Bearing
Profile:Complete with Outer and Inner Ring
Snap Ring:No
Internal Clearance:C0-Medium
Retainer:Yes
Relubricatable:Yes
Inch - Metric:Metric
Other Features:1 Rib Inner Ring | 2 Rib Outer Ring | Cage On Outer Ring ID
Long Description:80MM Bore; Straight Bore Profile; 140MM Outside Diameter; 26MM Width; Steel Cage Matetrial; RBEC 1 | ISO P0; Single Row; Inner Ring - One Side Separable; No Snap Ring; Relubricatable; C0-Medium Intern
UNSPSC:31171547
Harmonized Tariff Code:8482.50.00.00
Noun:Bearing
Manufacturer Item Number:NJ216
Weight / LBS:3.359
Width:1.024 Inch | 26 Millimeter
Bore:3.15 Inch | 80 Millimeter
Outside Diameter:5.512 Inch | 140 Millimeter
bore diameter::80 mm
static load capacity::122000 N
outside diameter::140 mm
precision rating::ISO Class 0
overall width::26 mm
maximum rpm::5700 rpm
flanges::(2) Outer Ring, (1) Inner Ring
bearing material::Hardened Alloy Steel
bore type::Straight
cage material::Pressed Steel
number of rows::1
finish/coating::Uncoated
internal clearance::CN
closure type::Open
operating temperature range::-40 to 120 ºC
fillet radius::2 mm
dynamic load capacity::106000 N
manufacturer product page::Click here
