SKF SAF 1613/C3 MODELS

Need a CAD or 3D Model?

Contact Now WhatsApp Be Our Agent

SKF SAF 1613/C3

SKF SAF 1613/C3 SPECIFICATIONS

Advance SKF SAF 1613/C3 0.0 Inventory is your source for quality Mounted Units and accessories. shop online N/A Minimum Buy Quantity for home delivery or pick up in one of our 10000 . Flange Block Category
Category:Flange Block
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:19.068
Product Group:M06288
Number of Mounting Holes:4
Mounting Method:Eccentric Collar
Housing Style:4 Bolt Round Flange Block

Download SKF SAF 1613/C3 Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

Information techniques SKF SAF 1613/C3

Rolling Element:Spherical Roller Bearing
Housing Material:Cast Steel
Expansion / Non-expansion:Expansion
Mounting Bolts:7/8 Inch
Relubricatable:Yes
Insert Part Number:22218
Seals:Triple Lip Nitrile Rubber
Housing Configuration:1 Piece Solid
Pilot Configuration:No Pilot
Inch - Metric:Metric
Long Description:4 Bolt Round Flange Block; 90MM Bore; 241MM Bolt Circle; 170.7MM Bolt Spacing; 1 Piece Solid; Eccentric Collar Mount; Cast Steel; Spherical Roller Bearing; 102.362MM Length Thru Bore; Relubricatable;
Other Features:Double Row
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Manufacturer Item Number:QMFY18J090SEM
Weight / LBS:42
Bolt Spacing:6.72 Inch | 170.7 Millimeter
D:4.03 Inch | 102.362 Millimeter
d:3.543 Inch | 90 Millimeter
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
Nominal Bolt Circle Diameter Round:9.5 Inch | 241 Millimeter
