SKF SAF 22509/C3

SKF SAF 22509/C3 SPECIFICATIONS

SKF SAF 22509/C3 Needs Analysis , Pillow Block Category 0.0 Inventory Mounted Units Manufacturing Service . Get Your Free.
Category:Pillow Block
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:14.528
Product Group:M06288
Number of Mounting Holes:2
Mounting Method:V Lock
Housing Style:2 Bolt Pillow Block

Download SKF SAF 22509/C3 Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

Information techniques SKF SAF 22509/C3

Rolling Element:Spherical Roller Bearing
Housing Material:Cast Steel
Expansion / Non-expansion:Expansion
Mounting Bolts:16 Millimeter
Relubricatable:Yes
Insert Part Number:22214
Seals:Triple Lip Nitrile Rubber
Housing Configuration:1 Piece Solid
Inch - Metric:Metric
Other Features:Double Row | Single Nut | SN Style
Long Description:2 Bolt Pillow Block; 65MM Bore; 80MM Base to Center Height; V Lock Mount; Spherical Roller Bearing; 196MM Minimum Bolt Spacing; 235MM Bolt Spacing Maximum; Relubricatable; Cast Steel; Triple Lip Nitri
UNSPSC:31171511
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Pillow Block
Manufacturer Item Number:QVSN14V065SEM
Weight / LBS:32
B:3.15 Inch | 80 Millimeter
Nominal Bolt Center to Center:8.5 Inch | 215.5 Millimeter
Bolt Spacing Minimum:7.717 Inch | 196Millimeter
D:3.189 Inch | 81 Millimeter
Bolt Spacing Maximum:9.252 Inch | 235Millimeter
Actual Bolt Center to Center:0 Inch | 0Millimeter
d:2.559 Inch | 65 Millimeter
