SKF SYR 3.15/16-18

SKF SYR 3.15/16-18 SPECIFICATIONS

SKF SYR 3.15/16-18, 2-3/4 in Shaft Size Units and Mounted Bearing Engineering Group Housings CAD models , Mounted Units Manufacturing Service . 22215 Bearing Number Get Your Free.
Engineering Group:Mounted Bearing
Bearing Number:22215
Shaft Size:2-3/4 in
Shaft Size Type:Imperial
Full Timken Part Number:QAAFL15A212SB
Locking Style:Double Concentric
Weight:23 lb
Housing Style:Four-Bolt Square Flange

Download SKF SYR 3.15/16-18 Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

Information techniques SKF SYR 3.15/16-18

UPC Code:0883450161497
Dimension BC:7.88 in
Dimension C:4.50 in
Dimension D:6.630 in
Dimension E:5.56 in
Dimension F:7.19 in
Dimension H:1.06 in
Dimension J (Bolt Size):0.75 in
Dimension L Exp:3.85 in
Dimension L Fix:3.77 in
Dimension M:2.37 in
Dimension N:2.930 in
Dimension RAA:0.97 in
Dimension SAA:4.74 in
C0 - Static Load:54100 lb
C - Dynamic Load (Basic):49900 lb
e - Geometry Factor:0.22
Y1 - Geometry Factor:3.01
Y2 - Geometry Factor:4.48
Oil Lubrication - M/N Seal:1600 rpm
Oil Lubrication - T Seal:2900 rpm
Oil Lubrication - B/C/O Seal:1300 rpm
Grease Lubrication - M/N Seal:1600 rpm
Grease Lubrication - T Seal:2400 rpm
Grease Lubrication - B/C/O Seal:1300 rpm
Float:0.083 in
Shaft Tolerance:0.0020 in
Eng Internal Radial Clearance - Min:0.0020
Eng Internal Radial Clearance - Max:0.0031
Pre Install Clearance Min:0.0020 in
Pre Install Clearance Max:0.0031 in
