SKF TU 1.3/4 WF

SKF TU 1.3/4 WF SPECIFICATIONS

What is SKF TU 1.3/4 WF in mechanical engineering? Pillow Block Category Mounted Units Manufacturing Service . Upload your CAD file for an instant.
Category:Pillow Block
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:25.878
Product Group:M06288
Number of Mounting Holes:4
Mounting Method:Concentric Collar
Housing Style:4 Bolt Pillow Block

Download SKF TU 1.3/4 WF Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

Information techniques SKF TU 1.3/4 WF

Rolling Element:Spherical Roller Bearing
Housing Material:Cast Steel
Expansion / Non-expansion:Expansion
Mounting Bolts:3/4 Inch
Relubricatable:Yes
Insert Part Number:22220
Seals:Teflon Labyrinth
Housing Configuration:1 Piece Solid
Inch - Metric:Metric
Other Features:Double Row | Double Collar | With Set Screw
Long Description:4 Bolt Pillow Block; 100MM Bore; 108MM Base to Center Height; Concentric Collar Mount; Spherical Roller Bearing; 276.225MM Minimum Bolt Spacing; 339.852MM Bolt Spacing Maximum; Relubricatable; Cast St
UNSPSC:31171511
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Pillow Block
Weight / LBS:67
d:3.937 Inch | 100 Millimeter
Bolt Spacing Minimum:10.875 Inch | 276.225Millimeter
Bolt Spacing Maximum:13.38 Inch | 339.852Millimeter
B:4.252 Inch | 108 Millimeter
Nominal Bolt Center to Center:12.1 Inch | 308.5 Millimeter
Actual Bolt Center to Center:0 Inch | 0Millimeter
D:5.94 Inch | 150.876 Millimeter
