THK C-S-20 USPP CS20 MODELS

Need a CAD or 3D Model?

Contact Now WhatsApp Be Our Agent

THK C-S-20 USPP CS20

THK C-S-20 USPP CS20 SPECIFICATIONS

THK C-S-20 USPP CS20 Product Brochures 0.0 Inventory , Thk Manufacturing Service . Get Your Free. Pillow Block Category
Category:Pillow Block
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:8.626
Product Group:M06288
Number of Mounting Holes:2
Mounting Method:V Lock
Housing Style:2 Bolt Pillow Block

Download THK C-S-20 USPP CS20 Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

THK C-S-20 USPP CS20 Code system

Rolling Element:Spherical Roller Bearing
Housing Material:Cast Steel
Expansion / Non-expansion:Expansion
Mounting Bolts:3/4 Inch
Relubricatable:Yes
Insert Part Number:22214
Seals:Triple Lip Viton
Housing Configuration:1 Piece Solid
Inch - Metric:Inch
Other Features:Double Row | Double Nut
Long Description:2 Bolt Pillow Block; 2-7/16" Bore; 3" Base to Center Height; V Lock Mount; Spherical Roller Bearing; 7.66" Minimum Bolt Spacing; 8.78" Bolt Spacing Maximum; Relubricatable; Cast St
UNSPSC:31171511
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Pillow Block
Manufacturer Item Number:QVVPXT14V207SEN
Weight / LBS:22
d:2.438 Inch | 61.925 Millimeter
Bolt Spacing Maximum:8.78 Inch | 223.012Millimeter
Actual Bolt Center to Center:0 Inch | 0Millimeter
B:3 Inch | 76.2 Millimeter
Nominal Bolt Center to Center:8.2 Inch | 208.3 Millimeter
D:4.09 Inch | 103.886 Millimeter
Bolt Spacing Minimum:7.66 Inch | 194.564Millimeter
