THK LXS OP-1 1M

THK LXS OP-1 1M SPECIFICATIONS

Various Thk types and sizes to accommodate Flange Block Category your THK LXS OP-1 1M requirements.
Category:Flange Block
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:52.21
Product Group:M06288
Number of Mounting Holes:6
Mounting Method:Concentric Collar
Housing Style:6 Bolt Round Flange Block

Download THK LXS OP-1 1M Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

THK LXS OP-1 1M Code system

Rolling Element:Spherical Roller Bearing
Housing Material:Cast Steel
Expansion / Non-expansion:Non-expansion
Mounting Bolts:1 Inch
Relubricatable:Yes
Insert Part Number:22226
Seals:Triple Lip Viton
Housing Configuration:1 Piece Solid
Pilot Configuration:No Pilot
Inch - Metric:Metric
Long Description:6 Bolt Round Flange Block; 130MM Bore; 355.6MM Bolt Circle; 177.8MM Bolt Spacing; 1 Piece Solid; Concentric Collar Mount; Cast Steel; Spherical Roller Bearing; 188.976MM Length Thru Bore; Relubricatab
Other Features:Double Row | Double Collar | With Set Screw
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Weight / LBS:115
Cartridge Pilot Diameter:0 Inch | 0 Millimeter
Cartridge Pilot Depth:0 Inch | 0 Millimeter
Bolt Spacing:7 Inch | 177.8 Millimeter
d:5.118 Inch | 130 Millimeter
Nominal Bolt Circle Diameter Round:14 Inch | 355.6 Millimeter
D:7.44 Inch | 188.976 Millimeter

THK LXS OP-1 1M pdf
