THK Y7B04 USPP Y7B04

THK Y7B04 USPP Y7B04 SPECIFICATIONS

THK Y7B04 USPP Y7B04, Units and Housings CAD 55x100x32 models , Thk Manufacturing Service . Get Your Free.
Bearing number:TR5510032
Size (mm):55x100x32
Bore Diameter (mm):55
Outer Diameter (mm):100
Width (mm):32
d:55 mm
D:100 mm
T:32 mm

Download THK Y7B04 USPP Y7B04 Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

THK Y7B04 USPP Y7B04 Code system

B:31 mm
C:24.5 mm
a:24.9 mm
r1 min.:2 mm
r2 min.:2 mm
r3 min.:2 mm
r4 min.:2 mm
Weight:1.052 Kg
Basic dynamic load rating (C):125 kN
Basic static load rating (C0):163 kN
(Grease) Lubrication Speed:3600 r/min
(Oil) Lubrication Speed:5000 r/min
Calculation factor (e):0.41
Calculation factor (Y):1.5

THK Y7B04 USPP Y7B04 pdf
