Home>Products>Plain Bearings>TSF.R 8.1 ISB h1 36 mm Plain bearings

TSF.R 8.1 ISB h1 36 mm Plain bearings MODELS

Need a CAD or 3D Model?

Contact Now WhatsApp Be Our Agent

TSF.R 8.1 ISB h1 36 mm Plain bearings

TSF.R 8.1 ISB h1 36 mm Plain bearings SPECIFICATIONS

What is TSF.R 8.1 ISB h1 36 mm Plain bearings in mechanical engineering? Plain Bearings Manufacturing Service . Upload your 0.0 Inventory CAD file for an Pillow Block Bearings Category instant.
Category:Pillow Block Bearings
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:25.28
Product Group:B04144
Number of Mounting Holes:2
Mounting Method:Clamp Collar
Housing Style:2 Bolt Pillow Block

Download TSF.R 8.1 ISB h1 36 mm Plain bearings Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

TSF.R 8.1 ISB h1 36 mm Plain bearings Product Features

Rolling Element:Cylindrical Roller Bearing
Housing Material:Cast Iron
Expansion / Non-expansion:Expansion
Mounting Bolts:24 Millimeter
Relubricatable:Yes
Insert Part Number:LSE303BX
Seals:Triple Lip Labyrinth
Housing Configuration:2 Piece Split
Inch - Metric:Inch
Other Features:Single Row | Light Duty | With Support | Wide Inner Ring | Axial Float
UNSPSC:31171511
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Pillow Block
Weight / LBS:55.68
Bolt Spacing Minimum:0 Inch | 0Millimeter
Actual Bolt Center to Center:12.6 Inch | 320Millimeter
Bolt Spacing Maximum:0 Inch | 0Millimeter
Nominal Bolt Center to Center:12.6 Inch | 320 Millimeter
B:4.409 Inch | 112 Millimeter
D:2.953 Inch | 75 Millimeter
d:3.188 Inch | 80.975 Millimeter
Shaft Size:3-3/16 in
Seal Type:Aluminium Triple Labyrinth
Bearing Type:Split Cylindrical Expansion Type
Support Type:Two-Bolt Plummer Block
Series Type:Light Series
Pillow/Plummer Block Style:Split Cylindrical Housed Unit - SAFQ
Bolt Size:2 x 7/8
Bearing Number:LSE303BX
Bearing UPC:013992026248
Dimension H:4-1/2 in
Dimension H2:9.6 in
Dimension J1:13-13/64 in
Dimension J2:11-47/64 in
Dimension L:15-23/64 in
Dimension M:4-11/32 in
Housing Width:5.4 in
Cr - Dynamic Load Rating:42145 lbf
Cor - Static Load Rating:52033 lbf
Maximum Speed:2790 rpm
Note:This product line was formerly known as “Revolvo”
