Home>Products>Plain Bearings>TUF1 22.150 Loyal b1 1.5 mm Plain bearings

TUF1 22.150 Loyal b1 1.5 mm Plain bearings MODELS

Need a CAD or 3D Model?

Contact Now WhatsApp Be Our Agent

TUF1 22.150 Loyal b1 1.5 mm Plain bearings

Name: TUF1 22.150 Loyal b1 1.5 mm Plain bearings
Brand: Loyal
SKU: 947131
Rating: 4.9 (5 reviews)

TUF1 22.150 Loyal b1 1.5 mm Plain bearings SPECIFICATIONS

Request A Quote For Your Flange Block Category 0.0 Inventory Special TUF1 22.150 Loyal b1 1.5 mm Plain bearings Needs Today! Free Plain Bearings Quotes. ISO 9001 certified.
Category:Flange Block
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:9.988
Product Group:M06288
Number of Mounting Holes:4
Mounting Method:Concentric Collar
Housing Style:4 Bolt Round Flange Cartridge

Download TUF1 22.150 Loyal b1 1.5 mm Plain bearings Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

TUF1 22.150 Loyal b1 1.5 mm Plain bearings Product Features

Rolling Element:Spherical Roller Bearing
Housing Material:Cast Steel
Expansion / Non-expansion:Non-expansion
Mounting Bolts:5/8 Inch
Relubricatable:Yes
Insert Part Number:22215
Seals:Double Lip Viton
Housing Configuration:1 Piece Solid
Pilot Configuration:With Pilot
Inch - Metric:Inch
Long Description:4 Bolt Round Flange Cartridge; 3" Bore; 7-1/2" Bolt Circle; 5.3" Bolt Spacing; 1 Piece Solid; Concentric Collar Mount; Cast Steel; Spherical Roller Bearing; 4.74" Length Thru Bore;
Other Features:Double Row | Double Collar | With Set Screw
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Weight / LBS:22
D:4.74 Inch | 120.4 Millimeter
Nominal Bolt Circle Diameter Round:7.5 Inch | 190 Millimeter
Bolt Spacing:5.3 Inch | 134.7 Millimeter
d:3 Inch | 76.2 Millimeter
Cartridge Pilot Depth:1.25 Inch | 31.75 Millimeter
Cartridge Pilot Diameter:6.375 Inch | 161.92 Millimeter

TUF1 22.150 Loyal b1 1.5 mm Plain bearings pdf
