TUP2 140.100 Loyal L 100 mm Plain bearings

Name: TUP2 140.100 Loyal L 100 mm Plain bearings
Brand: Loyal
SKU: 946698
Rating: 4.9 (5 reviews)

TUP2 140.100 Loyal L 100 mm Plain bearings SPECIFICATIONS

Browse TUP2 140.100 Loyal L 100 mm Plain bearings Categories N/A Minimum Buy Quantity in the Manufacturers Online Flange Block Category Free. including Plain Bearings.
Category:Flange Block
Inventory:0.0
Minimum Buy Quantity:N/A
Weight:18.16
Product Group:M06288
Number of Mounting Holes:4
Mounting Method:V Lock
Housing Style:4 Bolt Square Flange Cartridge

Download TUP2 140.100 Loyal L 100 mm Plain bearings Spec Sheet

Leader Industrial Manufacture

Leader Industrial ManufactureChina

Leader Industrial Manufacture2020-07-10 09:46:19
Welcome to my shop! Glad to serve you! Please send your question!

Interested In: Price Inspection Certificate Product Specifications Company Profile

TUP2 140.100 Loyal L 100 mm Plain bearings Product Features

Rolling Element:Spherical Roller Bearing
Housing Material:Cast Steel
Expansion / Non-expansion:Expansion
Mounting Bolts:3/4 Inch
Relubricatable:Yes
Insert Part Number:22220
Seals:Triple Lip Viton
Housing Configuration:1 Piece Solid
Pilot Configuration:With Pilot
Inch - Metric:Metric
Long Description:4 Bolt Square Flange Cartridge; 80MM Bore; 279.4MM Bolt Circle; 197.866MM Bolt Spacing; 1 Piece Solid; V Lock Mount; Cast Steel; Spherical Roller Bearing; 95.25MM Length Thru Bore; Relubricatable; Tri
Other Features:Double Row | Single Nut
UNSPSC:31171501
Harmonized Tariff Code:8483.20.40.80
Noun:Bearing
Keyword String:Flanged
Weight / LBS:40
Cartridge Pilot Depth:1.25 Inch | 31.75 Millimeter
Nominal Bolt Circle Diameter Round:11 Inch | 279.4 Millimeter
Bolt Spacing:7.79 Inch | 197.866 Millimeter
D:3.75 Inch | 95.25 Millimeter
d:3.15 Inch | 80 Millimeter
Cartridge Pilot Diameter:9.06 Inch | 230.124 Millimeter

TUP2 140.100 Loyal L 100 mm Plain bearings pdf
